Product Description
Battery Ready for DC Coupled and AC Coupled systems
Leading Functions
- Whole home backup
- Dark start operation
- Support RSD, AFCI and RGM meter
High Yields
- DC/AC Ratio up to 2.0
- MPP trackers up to 4
- Max. efficiency 98.5%
System Compatibility
- DC Coupled and AC Coupled systems
- Self-consumption, Zero Export, ToU and Off-grid
- UL1741SA/SB, CA Rule 21 & HECO
Warranty Information
| Warranty | 10 Years |
Product Videos
Product Reviews
Documentation
Specs
| Power Output | 7.6kW |
| AC Voltage | 240V |
| DC Voltage | 600V |
| Maximum Short Circuit DC Input Current | 16.9A |
| Maximum Operation DC Input Current | 13.5A |
| Number of MPPT's | 3 |
| MPP operating voltage window | 50-550V |
| Connectivity | RS485 |
| Display | Status LEDs |
| Cooling Method | Natural Convection |
| Number of DC Inputs | 3 |
| Connectivity Optional | WiFi/Ethernet |
| Battery Compatibility | Growatt APX battery |
| Inverter Type | Hybrid |
Shipping Dimensions
| Weight: | 35.00 LBS |
| Width: | 30.00 (cm) |
| Height: | 39.00 (cm) |
| Depth: | 68.00 (cm) |
