Product Description
- Positive power tolerance (0~ +5W)
- High module conversation efficiency
- Slower power degradation enabled by Low LID Mono PERC technology: first year <2%, 0.55% year 2-25
- Solid PID resistance ensured by solar cell process optimization and careful module BOM selection
- Adaptable to harsh environment: passed rigorous salt mist and ammonia tests
- Outstanding low light performance, average relative efficiency 97.5% or better at 200W/m2
- Reduced resistive loss with lower operating current
- Higher energy yield with lower operating temperature
- Reduced hot spot risk with optimized electrical design and lower operating current
Warranty Information
| Warranty | 25 Years |
Product Videos
Product Reviews
Documentation
| Datasheet |  Datasheet_Longi_LR5-66HPH-490-510M |
| Installation Manual | Manual_Longi_LR6 |
| Warranty PDF | Warranty_Longi_PV-Modules-(HE-Single-Glass-series)-V09 |
Specs
| Power Output | 505W |
| Peak Efficiency | 21.5 % |
| Type | 122-Half-Cell Module |
| Facial | Mono |
| Connection | MC4 |
| Container | 682 |
| Cell Count | 66 |
| Frame Colour | Silver |
| Backsheet Colour | White |
| Pallet Qty | 31 |
| Thickness | 35mm |
Shipping Dimensions
| Weight: | 55.40 LBS |
| Width: | 113.30 (cm) |
| Height: | 3.50 (cm) |
| Depth: | 207.30 (cm) |
