Product Description
Efficient
• 9/12/14 MPPTs, max. efficiency 99.0% (CEC efficiency 98.3%)
• > 1.5 DC/AC ratio
• High power tracking density 75MPPT/MW
• Compatible with 500W+ bifacial modules
Smart
• Intelligent string monitoring, smart I-V curve scan
• Remote firmware upgrade with simple operation
Safe
• Type 4X, C5 Anti-Corrosion Level
• UL 1741 SA and SB
• Integrated nighttime PID recovery for optimal module performance
• Fuse free design, safe and maintenance free
• AFCI protection, proactively reduces fire risk
• High quality components from globally recognized suppliers
Economic
• Power line communication (PLC) (optional)
• DC side supports "Y" connector
• Support aluminium wire to reduce cost
• Reserve DC energy storage access
Warranty Information
| Warranty | 10 Years |
Product Videos
Product Reviews
Documentation
| Datasheet |  Datasheet_Solis_125-255K-EHV-5G-US-Datasheet |
| Manual | Manual_Solis_Manual-3P(125-255)K-5G-US-V1.6(20221101) |
Specs
| Power Output | 255kW |
| DC Voltage | 1080V |
| Maximum DC Input Voltage | 1500V |
| Number Of MPPT's | 12 |
| Breaker | 200A |
| Cooling Method | Intelligent redundant fan-cooling |
| Inverter Type | String |
| Number of DC Inputs | 24 |
| Connectivity | RS485, Optional: PLC |
| Maximum Operation DC Input Current | 30A |
| Maximum Short Circuit DC Input Current | 50A |
| AC Voltage | 800V |
Shipping Dimensions
| Weight: | 250.00 LBS |
| Width: | 107.00 (cm) |
| Height: | 57.00 (cm) |
| Depth: | 34.00 (cm) |
