Product Description
Efficient
• 8 MPPTs, max. efficiency 98.5% (CEC efficiency 98.1%)
• > 1.5 DC/AC ratio
• String current up to 16A for higher capacity modules
Smart
• Intelligent string monitoring, smart I-V curve scan
• Remote firmware upgrade with simple operation
Safe
• Type 4X, C5 Anti-Corrosion Level
• UL 1741 SA and SB
• External signal control function
• Integrated nighttime PID recovery for optimal module performance
• AFCI protection, proactively reduces fire risk
• High quality components from globally recognized suppliers
Economic
• DC side supports "Y" connector
Warranty Information
| Warranty | 10 Years |
Product Videos
Product Reviews
Documentation
| Datasheet |  Datasheet_Solis_datasheet-S5-GC60K-LV-US-USA |
| Manual | Manual_Solis_Manual-S5-GC(75-125)K-US-V1.4(20210623) |
Specs
| Power Output | 60kW |
| DC Voltage | 450V |
| Maximum DC Input Voltage | 1000V |
| Number Of MPPT's | 8 |
| Breaker | 250A |
| Cooling Method | Intelligent redundant fan-cooling |
| Inverter Type | String |
| Number of DC Inputs | 16 |
| Connectivity | RS485, Ethernet, Optional: Wi-Fi, Cellular |
| Maximum Operation DC Input Current | 32A |
| Maximum Short Circuit DC Input Current | 50A |
| AC Voltage | 208V |
Shipping Dimensions
| Weight: | 200.00 LBS |
| Width: | 107.00 (cm) |
| Height: | 57.00 (cm) |
| Depth: | 34.00 (cm) |
